主要应用

高能二管泵浦，全固态，　Q-SWITCHEDLASER

高能二管泵浦固体，　q开关激光在532 nm的特性

　单脉冲能量高、短脉冲，时间和峰值功率高,

　广泛用于PIV、生活,库,icp，科学研究、激光加工、军事、等等。

产品特点

用于透明固体物质LIBS光谱检测的激光器。具有窄脉宽、高单脉冲能量等特点。

窄脉宽、高能量，可以有效击穿各类气体，适用于气体及液体样品LIBS光谱检测

1064 LIBS激光器

（100MJ-1000MJ）

NBET-L-1064/350~1000mJ\

HIGH ENERGY LAMP PUMPED SOLID STATE Q-SWITCHED LASER

High energy lamp pumped solid state Q-switched laser at 1064nm has the

features of high single pulse energy ， short pulse duration，and high peak

power，which is widely used in PIV, LIF, LIBS, ICP-MS, Raman，scientific research,

military ,and so on

技术参数

Wavelength (nm)      1064±1

Operating mode Q-switched: EOM (Electro-optic modulation)

Single pulse energy (mJ    350   500   700   1000

Pulse duration (ns)        <10 <10 <8 <8

Rep. rate (Hz) 1~10 (adjustable)

Energy stability<3%

Beam divergence, full angle (mrad) ~1 ~1 ~1 ~3

Beam diameter (mm)  7  8   8   9

Warm-up time (minutes) <15

Beam height from base plate (mm)80

Operating temperature (℃) 15~35

Power supply (220/110VAC) PSU-NBET-A(3U)

Expected lifetime of lamp (pulses) 107~108

Warranty period 1 year

Available Options SHG Module ;Higher Repetition Rates:≤20Hz ; Jitter:~1ns（Sdev）
