主要应用

高能二管泵浦，全固态，　Q-SWITCHEDLASER

高能二管泵浦固体，　q开关激光在1064 nm的特性

　单脉冲能量高、短脉冲，时间和峰值功率高,

　广泛用于PIV、生活,库,icp，科学研究、激光加工、军事、等等。

产品特点

用于透明固体物质LIBS光谱检测的激光器。具有窄脉宽、高单脉冲能量等特点。

窄脉宽、高能量，可以有效击穿各类气体，适用于气体及液体样品LIBS光谱检测

1064 LIBS激光器

（100UJ~100MJ）

NBET-S-1064/1~350μJ/1~2500Mw

LD PUMPED ALL-SOLID-STATE ACOUSTO-OPTIC Q-SWITHED LASER AT 1064 nm

All solid state acousto-optic Q-switched laser at 1064 nm has the features of high peak

power, high repetition rate, and short pulse duration, which is widely used in material processing，

 measure, scientific research and so on.

技术参数

Wavelength (nm)      1064±1

Single pulse energy (μJ) (350μJ @1kHz; 180μJ @10kHz)

Operating mode    ectro-optics Q-switched

Rep. rate (kHz) 0.1~100

Pulse duration Typically7~11ns @<10kHz, varies from power and repetition.

Average power (mW) Average power (mW)= Single pulse energy (μJ)* Rep. rate(kHz)

Power Stability (rms,over 4 hours) <3%,<5%,<10%

Transverse modeTEM00

M²<1.5

Beam Diameter at the aperture 1/e2 (mm) ~0.4 ~1.3 (optional)

Beam divergence, full angle (mrad) <5.0<1.5 (optional)

Polarization ratio>100:1 Horizontal±5 degree

Warm-up Time (minutes)<10

Beam height from base plate (mm)25

Operating temperature(℃) 10~35

Power supply (90-264VAC) PSU-NBETM-DL

Expected lifetime (hours) 10000

Warranty1 year

选型指南
